EMF measuring device for mobile use / distance control / earth connection / battery status display / simple operation
The EMF measuring device has a measurement range of 0.1 to 200 kV and an accuracy of ±10 % and is a test device for detecting the electrostatic voltage on the surface of objects. It uses non-contact measurement technology to detect the electrostatic field. The EMF measuring device has a hold function that allows measured values to be recorded and a zero function that can be used to set the device to "0" before each measurement.
The ideal measuring distance is 25 mm ±1.0 mm. The EMF measuring device is equipped with a 2-inch LC display with backlight, which allows the measured values to be read clearly even in poor lighting conditions. An automatic power off function after 5 minutes of non-use protects the batteries and extends the operating time. The EMF measuring device is powered by AAA batteries and, with a compact size of 140 x 75 x 35 mm and a weight of 122 g, is lightweight and portable.
In addition, the EMF measuring device has an earth connection to ensure proper earthing and therefore safety during use. This makes the meter versatile and suitable for use in electronics, plastics, chemicals and other industries.
Highlights
- measurement range: 0.1 … 200 kV
- measuring function: hold
- working distance: 25 mm ±1.0 mm
- LC display 2 inch with backlight
- earth connection
Technical specifications
Radiation Measuring range 0,1 … 200 kV DC Resolution 0,1 kV DC Accuracy±10 % General technical data Measuring functions HOLD Display type LCD with backlight Display size 2 Inch Current consumption meter 100 mA DC Automatic power-off 5 min Working distance 25 mm ±1.0 mm Protection class (device)IP20 (Rechargeable) battery 2 x 1,5 V AAA battery , Alkali-manganese Capacity 1200 mAh Operating conditions-18 … 50 °C , 0 … 85 % RH Storage conditions-18 … 50 °C , 0 … 85 % RH Dimensions ( L x W x H )140 x 75 x 35 mm Weight 122 g
Delivery scope
1 x EMF measuring device / EMF test device PCE-PSM 10 2 x 1.5 V AAA battery
