Voltmeter PCE-CBA 10
Car battery tester for testing 12V starter batteries/ LC display /
Starter and charging circuit measurement / Robust design / Easy to use
The voltage meter PCE-CBA 10 is a car battery tester and allows fast and easy testing of 12V voltage starting batteries. The voltmeter has various test modes to determine the condition of the car battery.The LC display of the voltmeter guides the user intuitively through the settings and various modes of operation.
The voltmeter is suitable for car batteries of the type DIN, KIS, IEC, EN, GB, SAE and MCA. To test the battery, the voltmeter can measure, inter alia, the starting current to determine the capacity of the car battery in the range between 30 and 100 Ah.
Technical specifications
General technical data Cable length 70 cm Connections Kelvin clamps Display type LCD Display size 2,4 Inch Measurement time 10 s Cold start current CCA 100 … 1700 A Battery capacities 30 … 100 Ah Battery standards JIS, DIN, IEC, IN, GB, SAE, MCA Menu language English, English (GB), German, French, Italian, Spanish, Polish, Russian Protection class (device)IP20 Power supply 12 V DC Operating conditions 0 … 50 °C , 0 … 90 % RH Storage conditions 0 … 50 °C , 0 … 90 % RH Dimensions ( L x W x H )125 x 73 x 21 mm Weight 244 g
