Gauss Meter / Tesla Meter for detecting magnetic field strengths and magnetic polarity / HOLD and ZERO function / LCD display with backlight
The magnetic strength meter is a portable measuring device for the precise detection of magnetic field strengths and for determining magnetic polarity. The device works with an integrated Hall sensor that reliably measures magnetic flux density and requires no wear-prone replacement parts. The display is shown on a backlit LCD display, which indicates the magnetic field strength in millitesla (mT); switching to gauss (Gs) is also provided. In addition, an LED display informs the user of the magnetic field polarity (red for north pole, green for south pole), ensuring clear identification of the field direction.
The Gauss Meter / Tesla Meter has functions such as HOLD for data storage and ZERO for zero-point adjustment, supporting stable and reproducible measurements. The measuring range is typically 0 … 2500 mT, with an accuracy of ±(5 % of reading +0.05 mT). Power is supplied by batteries, allowing mobile use.
The Gauss Meter / Tesla Meter is used in industrial measurement technology, in research and development, and in quality assurance. Typical applications include measuring magnetic fields on permanent magnets, electric motors, transformers and electromagnetic components. In addition, the Gauss Meter / Tesla Meter is used in teaching and in experimental setups to demonstrate and analyze electromagnetic relationships in practice.
Highlights
- Measuring range: 0 … 2500 mT
- LED display for magnetic field polarity (red for north, green for south)
- LCD display with backlight
- Measuring function – HOLD
- Zero-point adjustment – ZERO
- Units: mT, Gs
- Compact, handy design
Technical specifications
- Magnetic field DC — Measuring range: 0 … 2500 mT
- Magnetic field DC — Resolution: 0,01 mT
- Magnetic field DC — Accuracy: ±(5% of the mean value + 0.05 mT)
- General technical data — Measuring functions: HOLD
- Units mT, Gs — Display type: LCD with backlight
- Units mT, Gs — Display size: 1 Inch
- Units mT, Gs: Standard(s)IEC 610601-1
- Units mT, Gs — Menu language: English, English (GB)
- Units mT, Gs — Protection class (device): IP20
- Units mT, Gs — Power supply: batteries
- Units mT, Gs — (Rechargeable) battery: 2 x 1,5 V AAA battery , Alkali-manganese
- Units mT, Gs — Capacity: 1270 mAh
- Units mT, Gs — Operating conditions: 0 … 50 °C , 20 … 85 % RH
- Units mT, Gs — Storage conditions: 0 … 50 °C , 20 … 85 % RH
- Units mT, Gs — Dimensions: ( L x W x H )180 x 26 x 17 mm
- Units mT, Gs — Weight: 37,5 g
Delivery scope
- 1 x Gauss Meter / Tesla Meter PCE-MFM 2500
- 2 x 1.5V AAA batteries
- 1 x Operating instructions
