Compact and precise EMF measuring device / EMF test device / Magnetic field measurement in A/cm, Gauss or Tesla / With wireless interface / Axial measuring probe
The handy EMF measuring device / EMF test device is available as a single-handed device with an axial probe. This measures the magnetic field along the probe axis with a fixed measuring distance of 2.0 mm from the surface – ideal for precise measurements on flat surfaces or in boreholes. Despite its compact design, the EMF measuring device / EMF test device delivers high-precision measurement results – from weak field values just above the earth’s magnetic field to strong magnetic fields in the range of several thousand A/cm. Residual magnetism and remanence can also be reliably detected.
Whether as a EMF measuring device / EMF test device, magnetometer, gaussmeter or tesla meter – the MP-810A fulfils all requirements for modern magnetic field measurements. The terms refer to the same device – the high measuring accuracy and reproducibility of the results are decisive. A calibration standard (reference magnet) is also available, allowing you to check and document the accuracy of your magnetic field tester at any time. The wireless interface enables convenient connection to mobile devices and PCs via the free Lima Connect app. There you can manage projects, mark measuring points on photos, analyze results statistically and display them graphically – ideal for industrial quality assurance and research.
Highlights
- Measurement of direct and alternating magnetic fields
- Axial field probe
- OLED display
- Measured value memory for 4000 measurements
- Wireless interface
Technical specifications
- Magnetic field AC — Measuring range: 2 … 20000 A/cm
- Magnetic field AC — Resolution: 0,1 A/cm
- Magnetic field AC — Accuracy: in homogeneous field ± 1 A/cm up to 50 A/cm, ± 2% of measured value from 50 A/cm
- Magnetic field AC — Frequency: range 20 … 100 Hz
- Magnetic field DC — Measuring range: 0 … 20000 A/cm
- Magnetic field DC — Resolution: 0,1 A/cm
- Magnetic field DC — Accuracy: in homogeneous field ± 1 A/cm up to 50 A/cm, ± 2% of measured value from 50 A/cm
- General technical data — Measuring functions: Quantity, MAX, MIN, Average value, Standard deviation
- Units A/cm, kA/m, g, Oersted, T: Units additional information Units switchable (1 A/cm = 0.1 kA/m = 1.256 Gauss = 1.256 Oersted = 0.1256 mT)
- Units A/cm, kA/m, g, Oersted, T — Display type: OLED
- Units A/cm, kA/m, g, Oersted, T — Storage capacity: 4000 Values
- Units A/cm, kA/m, g, Oersted, T: Memory capacity (additional information)Peak value memory: Pulse time >= 0.25 sec
- Units A/cm, kA/m, g, Oersted, T — Interface: Wireless
- Units A/cm, kA/m, g, Oersted, T: Operating time 50 h
- Units A/cm, kA/m, g, Oersted, T — Menu language: German, English (GB), English, French, Italian, Spanish, Hungarian, Polish, Dutch
- Units A/cm, kA/m, g, Oersted, T — Protection class (device): IP64
- Units A/cm, kA/m, g, Oersted, T — Power supply: 1.5V AA Batterie
- Units A/cm, kA/m, g, Oersted, T — (Rechargeable) battery: 1 x 1,5 V AA battery , Alkali-manganese
- Units A/cm, kA/m, g, Oersted, T — Capacity: 3000 mAh
- Units A/cm, kA/m, g, Oersted, T: Performance 4,5 Wh
- Units A/cm, kA/m, g, Oersted, T — Operating conditions: 0 … 50 °C , 10 … 90 % RH
- Units A/cm, kA/m, g, Oersted, T — Storage conditions: 0 … 50 °C , 10 … 90 % RH
- Units A/cm, kA/m, g, Oersted, T — Dimensions: ( L x W x H )140 x 28 x 28 mm
- Units A/cm, kA/m, g, Oersted, T — Weight: 73 g
Delivery scope
- 1 x MP-810A EMF measuring device / EMF test device
- 1 x Spare battery
- 1 x Case
- 1 x Calibration certificate
