EMF measuring devicePCE-MFM 3500 Gauss meter with external sensor / Measuring range up to 30,000 G / Leveling bubble / Built-up memory for up to 7,000 values / Software for live view and reading / Battery and also mains operation / Sensor cable approx. 1 m (3.3 ft) / Battery life approx. 100 hours
The gauss meter is a reliable measuring device for measuring the existing magnetic field. This gauss meter is suitable for measuring both static (permanent magnet) and alternating magnetic fields. The flat probe of the external probe on the Milli-Gauss meter allows the operator to perform measurements even in very small openings. The measuring range of up to 30,000 G in the gauss meter covers a wide range of measuring tasks. In addition to measuring the magnetic field, the gauss meter also measures the temperature at the same time. The Milli-Gauss Meter also has an adjustable alarm function. This adjustable alarm function in the gauss meter warns the operator immediately as soon as a set measured value is exceeded.
As an additional function, the gauss meter has a memory function. Thanks to the built-in memory, measured values can be stored automatically as well as manually with the gauss meter. To analyze the measured data, the gauss meter can be connected to a PC via the mini-USB interface. With the software, the data stored on the gauss meter can be read out and analyzed. In addition, the software can be used for live viewing and operation of the gauss meter.
Highlights
- Adjustable alarm function
- Data memory with PC connection
- Temperature measurement
- Switchable AC / DC measurement
- Sensor alignment with bubble possible
- Rubber protective cover for the handset
Technical specifications
- Magnetic field AC — Measuring range: 0 … 150 mT
- Magnetic field AC — Resolution: 0,01 mT
- Magnetic field AC — Accuracy: ±(5% +20 digits) at 23°C ±5°C, <80% r. h.
- Magnetic field AC — Measuring range: 0 … 1500 mT
- Magnetic field AC — Resolution: 0,1 mT
- Magnetic field AC — Accuracy: ±(5% +20 digits) at 23°C ±5°C, <80% r. h.
- Magnetic field AC — Measuring range: 0 … 1500 g
- Magnetic field AC — Resolution: 0,1 g
- Magnetic field AC — Accuracy: ±(5% +20 digits) at 23°C ±5°C, <80% r. h.
- Magnetic field AC — Measuring range: 0 … 15000 g
- Magnetic field AC — Resolution: 1 g
- Magnetic field AC — Accuracy: ±(5% +20 digits) at 23°C ±5°C, <80% r. h.
- Magnetic field DC — Measuring range: 0 … 300 mT
- Magnetic field DC — Resolution: 0,01 mT
- Magnetic field DC — Accuracy: ±(4% +10 digits) at 23°C ±5°C, <80% r. h.
- Magnetic field DC — Measuring range: 0 … 2000 mT
- Magnetic field DC — Resolution: 0,1 mT
- Magnetic field DC — Accuracy: ±(4% +10 digits) at 23°C ±5°C, <80% r. h.
- Magnetic field DC — Measuring range: 2000,1 … 3000 mT
- Magnetic field DC — Resolution: 0,1 mT
- Magnetic field DC — Accuracy: N/A
- Magnetic field DC — Measuring range: 0 … 3000 g
- Magnetic field DC — Resolution: 0,1 g
- Magnetic field DC — Accuracy: ±(4% +10 digits) at 23°C ±5°C, <80% r. h.
- Magnetic field DC — Measuring range: 0 … 20000 g
- Magnetic field DC — Resolution: 1 g
- Magnetic field DC — Accuracy: ±(4% +10 digits) at 23°C ±5°C, <80% r. h.
- Magnetic field DC — Measuring range: 20001 … 30000 g
- Magnetic field DC — Resolution: 1 g
- Magnetic field DC — Accuracy: N/A
- Temperature — Measuring range: -20 … +50 °C
- Temperature — Resolution: 0,1 °C
- Temperature — Accuracy: ±1.0 °C
- Temperature — Measuring range: -4 … +122 °F
- Temperature — Resolution: 0,1 °F
- Temperature — Accuracy: ±1.8 °F
- General technical data: Cable length 1 m
- General technical data — Measuring functions: MIN, MAX, HOLD, peak
- General technical data — Display type: LCD
- General technical data: Measuring rate 1 Hz
- Storage medium Internal memory — Storage capacity: 7000 Values
- Storage medium Internal memory: Memory capacity (additional information)Manual: up to 200 values / automatic: up to 7000 values
- Storage medium Internal memory — Interface: Mini-USB
- Storage medium Internal memory — Sensor: Hall sensor
- Storage medium Internal memory: Operating time 100 h
- Storage medium Internal memory: Automatic power-off 15 min
- Alarm optical, Acoustic: Alarm modes If the measured value is within the set range, “GO” appears on the display.
- Alarm optical, Acoustic: If the measured value is outside the set limits, “NOGO” appears on the display.
- Alarm optical, Acoustic — Menu language: English, English (GB)
- Alarm optical, Acoustic — Protection class (device): IP20
- Alarm optical, Acoustic — Power supply 100 … 240 V AC: 50/60 Hz
- Connector type Device-europlug — (Rechargeable) battery: 6 x 1,5 V AAA battery , Alkali-manganese
- Connector type Device-europlug — Capacity: 1200 mAh
- Connector type Device-europlug — Operating conditions: 5 … 40 °C , 0 … 80 % RH
- Connector type Device-europlug — Storage conditions: 0 … 50 °C , 0 … 70 % RH
- Connector type Device-europlug — Dimensions: ( L x W x H )156 x 73 x 35 mm
- Connector type Device-europlug — Weight: 320 g
Delivery scope
- 1 x EMF measuring device / EMF test device PCE-MFM 3500
- 1 x Probe
- 1 x Mini USB cable
- 1 x Software CD
- 6 x AAA 1.5V batteries
- 1 x Power supply
- 1 x Device bag
- 1 x User manual
