Mobile three-phase poweranalyzer for voltages up to 400 VAC
The mobile three-phase power analyzer Easycount is an energy meter, installed in a splash-proof and impact-resistant housing, for three-phase current up to 400 V. The approx. 50 cm long cable ends of the mobile three-phase meter Easycount are equipped with a CEE plug and a CEE coupling. The plug and the coupling of the plug-in meter are adapted to the maximum permissible current of the meter (16 A). The built-in three-phase meter is calibrated according to the latest MID approval. The plug-in counter Easycount for three-phase current is ideally suited as a temporary electricity meter for DJs, as a construction site electricity meter, at street festivals and similar events where the electricity is to be billed but there is no permanently installed electricity meter.
Highlights
- Lightweight
- Easiest operation
- Can be used flexibly and in any position
- Easy to read display
- Stable ABS housing
- Connection cable lengths approx. 0.50 m / 19.6″ each
- With 16 A CEE connector
Technical specifications
- Technical Specifications: Voltage input 3 x 230 / 400 VAC
- Technical Specifications: Current carrying capacity 16 A
- Technical Specifications — Frequency: 50 Hz
- Technical Specifications — Power consumption: <0.5 W
- Technical Specifications: Minimum load 6 W
- Technical Specifications: Display 6+1 roller counter
- Technical Specifications — Resolution: 0.1 kWh
- Technical Specifications: Ambient temperature-20 … +50 ºC / -4 … 122 °F
- Technical Specifications: Degree of protection meter IP 54
- Technical Specifications: Degree of protection connector / coupling IP 44
Delivery scope
- Delivery contents Mobile three-phase power analyzer Easycount-3-16-A with approx. 0.50 m cable on both sides as well as CEE plug and CEE coupling already connected.
