PCE-PH20M Easy-to-usefood & hygiene meterfor pH determination / External pH electrode / Recalibratable / Waterproof (IP 67)
The food / hygiene meter was developed to directly determine the pH in aqueous media. The waterproof food / hygiene meter PCE-PH20 is used for the fast and accurate measurement of pH. The practical display makes the pH value on the pH meter easy to read. Due to the waterproof and robust housing (IP 67), the food / hygiene meter can also be used under difficult conditions. A recalibration always guarantees optimum accuracy and is very easy to perform using the optionally available calibration kits (automatic calibration function without calibration screws – to be performed only via the keyboard).
Highlights
- Waterproof (IP 67)
- Special external measuring electrode on cable
- High accuracy
- Auto-power-off for battery saver
- Supplied with calibration solutions
- Data hold function
- Easy-to-read digital display
- Easy to use
Technical specifications
- pH — Measuring range: 0 … 14 pH
- pH — Resolution: 0,01 pH
- pH — Accuracy: ±0.07 pH (within range 5 … 9 pH) / ±0.1 pH (within ranges 4 … 4.9 and 9.1 … 10 pH) / ±0.2 pH (within ranges 1 … 3.9 and 10 … 13 pH)
- Electrode: Designation CPC-OSH-12-01
- Electrode — Measuring range: 0 … 14 pH
- Electrode: Temperature range 0 … 60 °C
- Material of diaphragm Ceramics: Shank length 120 mm
- Material of diaphragm Ceramics: Shank diameter 12 mm
- Material of diaphragm Ceramics: Shank diameter additional information Sensor diameter: 6 mm
- Material of diaphragm Ceramics: Cable length 1 m
- General technical data — Measuring functions: HOLD
- General technical data — Display type: LCD
- General technical data — Display size: 1,35 Inch
- General technical data: Automatic power-off 10 min
- General technical data: Number of calibration points 3
- General technical data — Calibration: Automatically, at pH 4, pH 7, pH 10 using calibration solutions
- General technical data — Protection class (device): IP67
- General technical data — (Rechargeable) battery: 4 x 1,5 V AAA battery , Alkali-manganese
- General technical data — Capacity: 1200 mAh
- General technical data — Operating conditions: 0 … 60 °C , 0 … 80 % RH
- General technical data — Storage conditions: 0 … 60 °C , 0 … 80 % RH
- General technical data — Dimensions: ( L x W x H )180 x 40 x 32 mm
- General technical data — Weight: 220 g
Delivery scope
- 1 x pH meter PCE-PH20M
- 1 x pH electrode CPC-OSH-12-01 (for food)
- 4 x Battery
- 1 x Calibration kit with solutions pH4 + 7 (each 75 ml vial)
- 1 x Operating instructions
