Surface testing – coating thickness gauge PCE-CT 26FN For iron and non-ferrous substrates / Large measuring range / Rotatable color display / Low weight
The coating thickness gauge PCE-CT 26FN can measure non-destructive coatings (paints, plastics …) on steel / iron and non-ferrous metals. The coating thickness gauge is ideally suited, for example, to detect accidental damage to the vehicle immediately. But also in the industrial sector, the PCE-CT 26FN surface tester is used for incoming and outgoing inspection in order to be able to offer consistently consistent product qualities.
The ergonomically shaped coating thickness gauge with integrated probe and very simple operation allows you to quickly determine measurement results with high accuracy. The coating thickness gauge PCE-CT 26FN is designed for measurements of non-magnetic coatings such as lacquer, plastic, chrome, copper, zinc, enamel, etc. on steel and iron, as well as all insulating coatings such as lacquer, plastic, enamel, paper, glass, rubber etc. on copper, aluminum, brass, stainless steel and aluminum.
Application / use:
Simply place the coating thickness gauge u. read the measured value. You can easily measure varnish and paint layers, plastic layers, chrome layers, copper plating, zinc layers, galvanizing, enamel … on steel, stainless steel, iron and similar materials. Non-ferrous metals (copper, aluminum, brass) and anodized aluminum.
By means of the included standards you can adjust the coating thickness gauge at any time. To do this, the coating thickness gauge must be placed on one of the foils. Please make sure that the meter is seated straight / level.
Highlights
- Immediately ready to measure
- Wear-resistant sensor
- V-groove for measurement on pipes
- One-handed operation
- ISO calibration optional
- Incl. transport case
Technical specifications
- Layer thickness — Measuring range: 1 … 1250 µm
- Layer thickness — Resolution: 1 µm
- Layer thickness — Accuracy: ±(3% +2 µm)
- Layer thickness — Measuring range: 0 … 50 mil
- Layer thickness — Resolution: 0,1 mil
- Layer thickness — Accuracy: ±(3% +0.1 mil)
- Sensor — Battery: type Magnetic mode (Fe), Eddy current mode (NFe)
- Sensor: Measurable materials Fe substrates such as: steel, stainless steel, iron
- NFe substrates such as: copper, aluminium, brass: Min. measuring surface 5 x 5 mm
- NFe substrates such as: copper, aluminium, brass: Min. layer thickness Fe: min. 0.5 mm
- NFe substrates such as: copper, aluminium, brass: NFe: min. 0.3 mm
- NFe substrates such as: copper, aluminium, brass: Min. radius of curvature convex 3 mm
- NFe substrates such as: copper, aluminium, brass: Min. radius of curvature concave 50 mm
- General technical data — Measuring functions: MIN, MAX, Average value
- Units mils, µm — Display type: OLED
- Units mils, µm — Display size: 1,8 Inch
- Storage medium Internal memory — Storage capacity: 99 Values
- Storage medium Internal memory: Automatic power-off 90 s
- Storage medium Internal memory — Calibration: selectable: zero point, multipoint
- Storage medium Internal memory — Menu language: English, English (GB)
- Storage medium Internal memory — Protection class (device): IP20
- Storage medium Internal memory — (Rechargeable) battery: 2 x 1,5 V AAA battery , Zinc carbon
- Storage medium Internal memory — Capacity: 500 mAh
- Storage medium Internal memory — Operating conditions: 0 … 50 °C , 0 … 90 % RH
- Storage medium Internal memory — Storage conditions: 0 … 50 °C , 0 … 90 % RH
- Storage medium Internal memory — Dimensions: ( L x W x H )100 x 52 x 29 mm
- Storage medium Internal memory — Weight: 63,5 g
Delivery scope
- 1 x Surface Testing PCE-CT 26FN
- 2 x AAA batteries 1.5V
- 1 x Set of calibration foils (5 pieces)
- 1 x Fe standard block
- 1 x NFe standard block
- 1 x Transport case
- 1 x User manual
