Material Thickness Meter with magnetic induction (Fe) and eddy current (NFe) / 2.0-inch TFT colour display / Memory / Automatic switch-off / Compact design
The Material Thickness Meter has a measuring range of 0 … 2000 µm and enables non-destructive measurement of coatings on ferrous and non-ferrous metals. The resolution is 0.1 µm in the range of 0 … 99.9 µm and 1 µm in the range of 100 … 2000 µm. Accuracy is ≤ ±(3% of reading + 2 µm). The Material Thickness Meter automatically detects the base material and independently selects the appropriate measuring method. Magnetic induction (Fe) is used for ferrous metals and the eddy current method (NFe) for non-ferrous metals.
The Material Thickness Meter supports the units µm, mm and mil and has a measuring rate of 0.5 measurements per second. The minimum thickness of the base material is 0.3 mm, while the minimum convex curvature radius is 5 mm and the minimum concave curvature radius is 25 mm. Zero calibration and 2-point calibration are available for calibration. The measured values are shown on a 2.0-inch TFT colour display.
The internal memory can store up to 30 measured values; when the memory is full, the oldest measured values are overwritten. The stored measurement data can be transferred to a computer and read out there via the USB-C interface. In addition, the Material Thickness Meter has an automatic switch-off function that can be set from 5 to 30 minutes. The compact Material Thickness Meter is suitable, among other things, for checking paintwork, coatings, corrosion protection layers and electroplated layers in quality control, production, maintenance and materials testing.
Highlights
- Automatic base material detection
- Automatic selection of measuring method
- Measuring method: magnetic induction (Fe) / eddy current (NFe)
- Units: µm, mm, mil
- Internal memory for up to 30 measured values
Technical specifications
- Layer thickness — Measuring range: 0 … 99,9 µm
- Layer thickness — Resolution: 0,1 µm
- Layer thickness — Accuracy: ≤ ±(3% of measured value +2 µm)
- Layer thickness — Measuring range: 100 … 2000 µm
- Layer thickness — Resolution: 1 µm
- Layer thickness — Accuracy: ≤ ±(3% of measured value +2 µm)
- Sensor — Battery: type Magnetic mode (Fe), Eddy current mode (NFe)
- Sensor: Min. thickness of base material 0,3 mm
- Sensor: Min. radius of curvature convex 5 mm
- Sensor: Min. radius of curvature concave 25 mm
- Sensor: Additional description The device automatically detects the base material and independently selects the appropriate measuring method.
- Units µm, mm, mils — Display type: TFT colour display
- Units µm, mm, mils — Display size: 2 Inch
- Units µm, mm, mils: Measuring rate 0,5 x per second
- Storage medium Internal memory: Memory information Ring buffer for 30 measured values
- Storage medium Internal memory — Interface: USB-C
- Storage medium Internal memory: Automatic power-off from…to 5 … 30 min.
- Storage medium Internal memory — Calibration: Zero calibration / 2-point calibration
- Storage medium Internal memory — Menu language: English, English (GB), Chinese
- Storage medium Internal memory — Protection class (device): IP20
- Storage medium Internal memory — Power supply: Battery or 5V DC (USB-C)
- Storage medium Internal memory — Operating conditions: -10 … 50 °C , 10 … 90 % RH
- Storage medium Internal memory — Storage conditions: -20 … 60 °C , 10 … 90 % RH
- Storage medium Internal memory — Dimensions: ( L x W x H )130 x 58 x 30 mm
- Storage medium Internal memory — Weight: 80 g
Delivery scope
- 1 x Material Thickness Meter PCE-CT 5
- 1 x FE reference plate
- 1 x AL reference plate
- 6 x Thickness standard plates
- 1 x USB-C cable
- 3 × 1.5V AAA batteries
- 1 x Carrying case
- 1 × Operating instructions
