Vacuum pump in robust housing / Flow rate from 340 … 407 l/min / Filter to reduce oil mist / Connections: 1/4 inch and 3/8 inch
The Vacuum pump is equipped with a powerful motor that provides sufficient torque for stable operation. The motor power is 1.014 hp (750 W) and ensures reliable and efficient performance. With a flow rate of 340 … 407 l/min, the HVAC Vacuum pump can quickly remove air and moisture from air conditioning systems, cooling systems or heat pumps.
The Vacuum pump has 1/4 inch and 3/8 inch connections, which increases its versatility and adaptability to different refrigerant hoses and applications. An integrated filter element effectively reduces oil mist, extends the service life of the Vacuum pump and ensures a cleaner working environment. The ergonomic rubber handle enables safe transport and easy handling.
The Vacuum pump is used to evacuate air conditioning systems, cooling systems or heat pumps before filling them with refrigerant. This removes moisture and air from the system, which improves the efficiency and service life of the system.
Highlights
- For refrigerants (e.g. R12, R22, R134a)
- High torque and efficient motor
- Motor power: 1.014 hp (750 W)
- Flow rate: 340 … 407 l/min
- Connections: 1/4 inch and 3/8 inch
- Ultimate vacuum: 15 micron / 0.02 mbar
- Filter element to reduce oil mist
- Comfortable and robust rubber handle
Technical specifications
General technical data Cable length 130 cm Connections 1/4 inch SAE, 3/8 inch SAE Motor power 1,014 PS Oil capacity 780 ml Ultimate vacuum 0,02 mbar Flow rate 340 … 407 l/min Protection class (device)IP20 Power supply 220 V AC | 50 Hz Connector type Schuko plug Operating conditions 5 … 40 °C , 20 … 80 % RH Storage conditions 5 … 40 °C , 20 … 80 % RH Dimensions ( L x W x H )390 x 140 x 250 mm Weight 13510 g
Delivery scope
1 x Vacuum pump PCE-RVP 1200 1 x Vacuum pump oil 300 ml 1 x Vacuum pump oil 450 ml 1 x Instruction manual
