Fixed Installation Cleanroom Particle Counter / Cleanroom Dust Meter / Measurement of Flow and Volume Flow via Ultrasonic / Compatible with Various Pipe Materials and Fluids / Analog Output 4 … 20 mA / RS485 Interface
Our fixed installation Cleanroom Particle Counter / Cleanroom Dust Meter offers the capability to measure flow rates from ±0.1 m/s to ±5 m/s using ultrasonic technology. This Cleanroom Particle Counter / Cleanroom Dust Meter is suitable for small pipes with a diameter of DN25 / 1″ and is compatible with various pipe materials such as steel, copper, aluminum, and plastics. Due to its compact design, it can be quickly and easily mounted on the pipe. The Cleanroom Particle Counter / Cleanroom Dust Meter’s display provides information on flow velocity, date, and time. In another view, it also displays the volume flow rate for the day, month, and year. Additionally, the Cleanroom Particle Counter / Cleanroom Dust Meter can output the measurement value as an analog signal (4 … 20 mA) and digitally via an RS485 interface. With a power supply range of 9 … 36 V DC, the fixed installation Cleanroom Particle Counter / Cleanroom Dust Meter is highly versatile and can be used in a wide range of applications. It comes with a 2 m connection cable and coupling pads for improved signal transmission. This Cleanroom Particle Counter / Cleanroom Dust Meter can be used in various applications, including heating systems, cooling water systems, and industrial processes where flow monitoring and control are necessary.
Highlights
- Measurement Range ±0.1 m/s … ±5 m/s
- Display of Flow, Volume Flow
- Pipe Size: DN25
- Suitable for Various Pipe Materials and Media
- Analog Output: 4 … 20mA
- Interface: RS485
Technical specifications
- Speed — Measuring range: 0,1 … 5 m/s
- Speed — Resolution: 0.001 m/s
- Speed — Accuracy: 2 % of Rd
- General technical data: Analogue output 4 … 20 mA
- General technical data — Display type: OLED
- General technical data — Interface: RS485
- General technical data: Materials PVC, Steel, Stainless steel, Copper, PVDF (Polyvinylidene fluoride), PFA (perfluoroalkoxy polymers), PTFE (Polytetrafluoroethylene), PU (Polyurethane), Aluminium
- General technical data: Measured medium Water, Seawater, Oil, User-defined (manual entry of the sound velocity of the medium)
- General technical data — Menu language: English, English (GB)
- General technical data — Protection class (device): IP54
- General technical data — Power supply: 9 … 36V DC
- General technical data — Operating conditions: 0 … 50 °C , 0 … 95 % RH
- General technical data — Storage conditions: 0 … 50 °C , 0 … 95 % RH
- General technical data — Dimensions: ( L x W x H )110 x 58 x 67 mm
- General technical data — Weight: 514 g
Delivery scope
- 1 x Fixed Installation Cleanroom Particle Counter / Cleanroom Dust Meter PCE-UFM 25
- 1 x 2m Connection Cable
- 4 x Coupling Pads
- 1 x User Manual
